TCP/IP5017andTCP/IP5018
Bydefault,theseportsareavailable.However,youcanchangethemandaddorremoveother
ports.
Client–SelectthischeckboxtoenteraRemoteIPandport.Thisenablesthereceivertoinitiatea
connectiontotheremoteserver.Thiscanbe
usedwhenthereceiverisbehindanetworkfirewall
orhasadynamicIPaddress.
OutputOnly/AllowMultipleTCP/IPConnections–Selectthischeckboxtoconfigurethereceiver
sothatitcanbroadcasttomultiplesimultaneousremotes.Theremotesareunabletosenddata
backtothereceiver.Trimble
stronglyrecommendsthissettingforallportswithoutatwo‐waydata
requirement.Ifthisisnotenabled,remotescanreconfigurethereceiver.
UDPMode–SelectthischeckboxtouseUDP(UserDatagramProtocol)insteadofTCP.Youcan
editaUDPtimeout.Bydefault,itisset
to60seconds.
Authenticate,setpassword–Selectthischeckboxsothatallincomingconnectionsarerequiredto
enterapasswordtoauthenticatetheconnection.ThisisnotNTRIPauthentication.
PortSelection
 Port–Thefirstdrop‐downlistdisplayswhichtypeofportisavailableforconfiguration.

OutputType–Theseconddrop‐downlistdisplayswhichoutputtypeissentoutofeachport.
Oneofthefollowingoutputgroupsappearswithconfigurationsettings,dependingontheoption
thatyouselectinthedrop‐downlistatthetopofthepage:
 CMR

 RTCM

 NMEA

 RT17/RT27

 BINEX

 GSOF

 OMNISTAR

AddTCP/IPorUDPPort
SelectthisoptiontoaddanewTCP/IPporttothereceiver.
UDPMode–SelectthischeckboxtouseUDP(UserDatagramProtocol)insteadofTCP.
LocalPort#–SelecttheportnumberthatistobeusedandthenclickAddto
createthe
configuration.
Oneofthefollowinggroupsappears,dependingontheoptionthatyouselectinthedrop‐downlist
atthetopofthepage:
