Trimble TSC3 - Device Hardware Overview; Front and Back Views

4
Device Hardware
Front View
Back View
NOTE: Some features are offered as options and may not apply to your unit. Be sure
to read the warranty and safety information in this manual prior to using your unit.
Notification
LEDs
Enter
Power
Battery Door
Latch
(under
hand strap)
Battery
Door
Hand
Strap
Stylus
2.4 GHz
Antenna
(if present)
Navigation
Pad
Enter
Dual LED
Camera
Flash
Qwerty
Keypad
Camera
