www.highwayguardrail.com 9 Revised: October 5, 2009
PN Description
6321G
3
/
8
” x 2’ (10 x 50) Hex Head Bolt (High Strength)
6405G
3
/
8
” (10) Hex Nut
6907B
Polymer Block 4” x 7
1
/
2
” x 14” (100 x 187 x 350) [King
Block]
14329G
#
3’ 6
5
/
8
” SYTP Stub
14578G
#
6’ Steel Yielding Terminal Post (SYTP)
33871A
#
ET HBA Post #1 Top
33873A
#
ET HBA Post #1 and #2 Bottom
33874A
#
ET HBA Post #3 - #8 Bottom
33877A
#
ET HBA Post #2 - #8 Top
9852A
#
Strut (and Yoke Assembly)
33875G
#
6' 6" (1980) Angle Strut ET HBA
33795G
#
6’ 6” (1980) Angle Strut
33730G
#
6’ 7
1
/
2
” (1980) Angle Strut
33847G
#
6’ 9
1
/
8
” Angle Strut
* Option to the 6’0” Post Sleeve Tube
#
Review the state/specifying agency’s standard drawings of these
systems, for details that are specific to the project or site locations.
Delineation Options
PN Description
6206B
Right Side 13” x 27
1
/
2
” (325 x 700) Reflective Sheeting
6207B
Left Side 13” x 27
1
/
2
” (325 x 700) Reflective Sheeting
6668B
Either Side 12” x 12” (305 x 305) Reflective Sheeting
(Typically 2 required)
Revised: March 2010
To Next Page
