Trinity TBFC-2204 User Manual

INSTALLATION INSTRUCTIONS – In Cabinet
STEP 3
Align LOWER DRAWER (A) at marked location
and push it into clips of LEFT & RIGHT SLIDES (B)
& (C).
Installation Suggestion: With LOWER DRAWER
(A) resting on top of the clips, brace the top of
LOWER DRAWER (A) with one hand and, with a
rubber mallet, lightly tap each bottom corner of
the CLIPS to secure LOWER DRAWER (A) into the
clips.
STEP 4
Remove black caps from 2 corner posts of
LOWER DRAWER (A). Insert 2 CONNECTORS
(H) into posts of bottom basket. Place UPPER
DRAWER (I) on connectors.
Note: UPPER DRAWER (I) can be placed
on either right hand side or left hand side.
3
