ASSEMBLY INSTRUCTIONS
Place the LARGE SHELF (A) on its side and
slide the (6) BOTTOM POLES (F) through the
holes in the LARGE SHELF (A). Make sure
that the LARGE SHELF (A) corner cylinders
are positioned over the SLIP SLEEVES (J).
Stand the unit upright.
*Note: The level side of the LARGE SHELF (A)
is the TOP side (the TRINITY logo on the
corner cylinders should be right-side up.)
**Use a rubber mallet, if needed, to secure the
LARGE SHELF (A).
STEP 3
A (1)
A
© 2016 TRINITY - 800.985.5506
4
***For convenience, place BOTTOM POLES (F) with Locking Casters on the long side of the
shelf if the organizer will be pushed against a wall OR if the organizer is frequently rolled around
like a cart, place BOTTOM POLES (F) with Locking Casters on the side being pushed or pulled.
Screw the MIDDLE POLES (E) into the
BOTTOM POLES (F).
STEP 4
E (6)
E
To Next Page
