Your TRINITY Stainless Steel Utility Sink w/Pull-out Faucet should include the following parts. Please
inspect box contents to ensure you have received all components.
If you are missing any parts, need assistance with assembly or have questions, please contact
TRINITY Customer Service: 800.985.5506 or customerservice@trinityii.com. Parts can also be
requested online at www.trinityii.com (Help & More, Contact Us).
A Phillips head screwdriver is required for assembly, and a pipe wrench is recommended.
SINK (1)
A
LEG (4)
w/ Feet Leveler
B C
HEX KEY (1)
FAUCET
ASSEMBLY (1)
w/ Hoses
DRAIN
ASSEMBLY (1)
P-trap not included
G
HEX SCREW
(18) + (2) extra
(8) are pre-installed on sink,
(10) are pre-installed on connectors.
I
F J
M
BRACKET (1)
MOUNTING SCREW
(2)
ANCHOR
(2)
PARTS LIST
D
SCREW CAP (8)
N
E
SHORT CROSS
BEAM (2)
LONG CROSS
BEAM (1)
H
2-WAY
CONNECTOR (2)
3-WAY
CONNECTOR (2)
K L
© 2019 TRINITY - 800.985.5506
