Trio JR900 - Default Chapter; Table of Contents

Page 2
J-Series Data Radio – User Manual
Issue 09-10
Part F – Quick Reference Guide 34
Introduction 34
Mounting and Installation Instructions 35
Physical Dimensions - Remote Ethernet Data Radio 35
Connecting Antennas and RF Feeders 36
J-Series Connections Layout 36
Power Supply Requirements 36
Communication Ports 37
Cable Termination 37
Serial Port A & B Ports 38
LED Indicators 39
J-Series Conguration (Web Interface) 40
Resolving Ethernet Conguration Problems 41
Multi Master Synchronisation 43
Text User Interface (TUI) 44
Spectrum Analyzer 48
SNMP 50
eDiagnostics 52
Part G – Quick Start Guide 54
Point to Point Ethernet Link Setup 54
Point to Point - TCP Serial Device Server Setup Guide 57
Point to Point - UDP (Unicast) Serial Device Server Setup Guide 58
Point to Multi-Point - UDP (Multicast) Serial Device Server Setup
Guide 59
Point to Multi-Point with Peer to Peer - UDP (Multicast to Multicast)
Serial Device Server Setup Guide 61
Part H – Installation & Commissioning 63
Optimizing the Antenna for Rx Signal 65
Commissioning 66
Part I – Firmware Updating 68
Part J – FCC Approved Antennas 70
Part K – Support Options 71
Website Information 71
E-mail Technical Support 71
Contents
Part A – Preface 3
Warranty 3
Important Notice 3
FCC Compliance Notices 3
Australian Compliance Notices 3
EU (ETSI) Compliance Notices 3
Part B – J-Series Overview 5
Introduction 5
Product Range 5
Features and Benets 5
Ordering Information 7
Standard Accessories 8
Part C – Network Types 9
Introduction 9
Point-to-Point Networks (PTP) 9
Point-to-Multipoint Networks (PTMP) 10
Point-to-Multipoint via KwikStream™ Repeater 11
Point to Point with LinkXtend™ Bridge (PTP/B) 12
Point to Multipoint via LinkXtend™ Bridge (PTMP/B) 13
Part D – Features 14
Features Useful for Optimizing Performance. 14
Multi-Access Point Synchronization 16
Digital Collision Avoidance 17
Retries and Retransmissions 17
Ethernet Trafc Filtering 18
Security 18
SmartPath™ 20
Diagnostics Tools 26
Text User Interface (TUI) 27
Spectrum Analyzer and Channel Lockout Facility 27
Legacy Serial Support 28
Part E – RF Planning and Design 31
Understanding RF Path Requirements 31
Examples of Predictive Path Modelling 31
Antennas 32
RF Feeders and Protection 33
Band Pass Filter (900MHz Only) 33
