6
RECOMMENDED INSTALLATION
The following diagrams and information detail the typically required Surge Protection,
EMC Earth and Cable Shields however more comprehensive information can be found in
the corresponding Product Technical Manual (available at www.triomotion.com)
SURGE PROTECTION
SINGLE POWER SUPPLY
Where the device is supplied with 24V dc from one dedicated 24V power source and
the connecting cable is less than 3 metres, there is no need for a separate surge
protection device.
24V dc
POWER SUPPLY
AC
SUPPLY
< 3M LONG
Motion Coordinator
Motion Coordinator with dedicated power source
