1- Mount the brackets on the box, using 2xM6x25 countersunk head bolt + nut for each
bracket, in the positions shown above. ONLY FOR REAR SEAT: mount a bracket in the
middle of the box rear wall, upside down compared to the other brackets (use the bolts and
nuts from the steering column). USE A TORQUE OF 8 Nm MAX.
REAR SEAT
FRONT SEAT
2- Connect seat belt shoulder holders to the rear wall on the box with 2xM6x25 bolt + nut
each in the specific countersunk holes.
USE A TORQUE OF 8 Nm MAX.
ALL PICTURES SHOW 4 KIDS CONFIGURATION
6
7
ASSEMBLING THE SEAT
