ASSEMBLING THE SEAT ASSEMBLING THE SEAT
3- Connect seat belt shoulder holders to the front wall on the box with 2x M5x12 non-
countersunk bolt each in the specific threaded holes.
USE A TORQUE OF 5 Nm MAX.
9
4- Connect seat belt bottom parts to the box floor, using 1xM6 bolt each in the specific
threaded holes. USE A TORQUE OF 5 Nm MAX.
8
