ASSEMBLING THE BIKE
4- Mount the handlebar using the 4 M6 bolts (the ones with washers on the top, the ones
without on the bottom) + 4 M6 nuts (bolt outside, nuts inside). If the bike is equipped with
the Supernova Lights Kit, fix the light cables installing the specific cable stoppers under
the box. The provided screws are self-tapping so you have freedom of positioning. Consider
that when the bike is turning the external cable gets shorter.
17
