GENERAL SPECIFICATIONS
FRAME: aluminium 7005
BOX: vacuum formed ABS + PU foam – sandwich
REAR WHEEL: 26”
FRONT WHEELS: 20”
BRAKES: Tektro hydraulic disc brakes on front, Shimano hydraulic disc brake on rear
GEARS:
Shimano Nexus 8 speeds internal hub
Shimano Deore 9 speeds (E VERSIONS ONLY)
Enviolo CA (MID DRIVE MOTOR VERSION ONLY)
E-SYSTEMS:
MID DRIVE VERSION:
Brose Drive S | 250W – 90 Nm
BATTERY: Li-Ion cells, 36V – 468 Wh
OPTION: 612 Wh battery
REAR DRIVE VERSION:
Promovec 250W – 43 Nm
BATTERY: Li-Ion cells, 36V – 461 Wh
OPTION: 500W motor
TRANSMISSION: chain
OVERALL DIMENSIONS:
OVERALL: length 225 cm, width 91 cm
BOX:
WIDTH: outside 80 cm, inside 74 cm
LENGTH: outside 113 cm, inside 83 cm
TOTAL WEIGHT: 32 Kg (non electric version), 44 Kg (electric version)
MAX PAYLOAD ON THE FRONT BOX: 110 Kg
OVERALL MAX PAYLOAD: 240 Kg
