TRIOMED UNIVERSAL. USER MANUAL
13
4. TECHNICAL AND OPERATIONAL
CHARACTERISTICS
4.1. General technical characteristics
The device and radiators are produced without using
any harmful chemical substances in compliance with the
TRIOMED EU Ltd technical documents and meet the re-
quirements of Directives 93/42/EEC and 2007/47/EC.
As far as potential risks of use are concerned, the device
is classied as Class IIa equipment according to Directive
93/42/EEC and has been designed as a product with internal
safe power supply.
The device consists of three parts (Fig 1):
•
low-frequency electronic TRIOMED generator (power unit);
•
external radiators 1 and 5 (other MM EMR radiators as
well as the IR radiator can be purchased separately);
•
standard cable (USB А – miniUSB B 5 pin).
1– radiator
2– mini USB В 5
pin connector
3– cable
4–USB A
connector
5–power supply
unit
Figure1.
Generalviewoftheradiatorandthecable
