Standard Extender/Splitter Installation
10
Repeat step 9 for each additional monitor you are connecting.
11
TurnonthepowertotheHDMIsource.TheorangeRJ45LEDs
illuminate on the B126-002 and B126-004 to indicate the unit
is receiving a signal from the source. The screen should now be
displayed on the connected monitors.
12
If necessary, use the Equalization control on the B126-1A0 or
B126-1A0-WP-1 to adjust the video image.
Note: An improper Equalization setting can cause the monitor not to
display a picture at all. Try each Equalization setting until an acceptable
picture is displayed.
