Tripp Lite B126-1A1-WP User Manual

25
1
Make sure the HDMI source is powered OFF.
2
ConnecttheHDMIsourcetotheINPUTportontheB126-004using
aTrippLiteP568-SeriesHDMICable.
3
ConnecttheLOCALportontheB126-004totheINPUTportona
second B126-004 using the included 1-ft. HDMI daisy-chain cable.
4
Repeatstep3ifyouwanttoconnectathirdB126-004.
5
Optional: Connect a local monitor to the LOCAL HDMI port of the
lastB126-004usingaTrippLiteP568-seriesHDMIcable.
6
ConnecttheexternalpowersupplytotherstB126-004inthe
daisy-chain and plug it into a Tripp Lite Surge Suppressor, PDU or
UPS.ThegreenRJ45LEDsandtheredPowerLEDonthe
B126-004 will illuminate to indicate power is being received from
the external power supply.
7
Repeat step 6 for each additional B126-004 in the daisy-chain.
8
UsingCat5e/6cable,connectoneoftheRJ45outputportsonthe
localunittotheRJ45inputportontheB126-110remote/repeater
unit.
9
Connect a monitor to the HDMI OUTPUT port on the remote/repeater
unitusingaTrippLiteP568-SeriesHDMICable.
10
Connect the external power supply to the remote/repeater unit and
plug it into a Tripp Lite Surge Suppressor, PDU or UPS. The green
powerLEDandthegreenRJ45LEDsilluminatetoindicatetheunit
is receiving power.
Upto4unitscanbedaisy-chained(3remote/repeatersand1receiver).
To connect additional remote/repeater units, proceed to step 11. To
nishyourinstallationwithaB126-1A0orB126-1A0-WP-1remote
receiverunit,proceedtostep15.
Extender/Splitter Daisy-Chain with
Remote/Repeater Installation (B126-004 only)
201109206-93-3023-EN.indd 25 10/24/2011 10:01:26 AM

Tripp Lite B126-1A1-WP Specifications

General

Brand	Tripp Lite
Model	B126-1A1-WP
Category	Extender
Language	English
