Tripp Lite B126-1A1-WP User Manual

26
Extender/Splitter Daisy-Chain with
Remote/Repeater Installation (B126-004 only)
11
UsingCat5e/6cable,connecttheRJ45OUTPUTportontherst
remote/repeaterunittotheRJ45INPUTportonasecondremote/
repeater unit.
12
Connect a monitor to the HDMI OUTPUT port on the remote/repeater
unitthatyoujustaddedusingaTrippLiteP568-SeriesHDMICable.
13
Connect the external power supply to the remote/repeater unit and
plug it into a Tripp Lite Surge Suppressor, PDU or UPS. The green
powerLEDandthegreenRJ45LEDsilluminatetoindicatetheunit
is receiving power.
14
Toaddathirdremote/repeaterunit,repeatsteps11through13.To
nishyourinstallationwithaB126-1A0orB126-1A0-WP-1remote
receiverunit,proceedtostep15.
15
UsingCat5e/6cable,connecttheRJ45OUTPUTportonthelast
remote/repeaterunittotheRJ45INPUTportonaB126-1A0or
B126-1A0-WP-1 remote receiver unit.
16
Connect a monitor to the HDMI OUTPUT port on the remote receiver
unitusingaTrippLiteP568-SeriesHDMICable.
17
Connect the external power supply to the remote receiver unit and
plug it into a Tripp Lite Surge Suppressor, PDU or UPS. The green
LED illuminates to indicate the unit is receiving power from the
external power supply. The orange LED illuminates to indicate the
unitisconnectedtoapoweredONremote/repeaterunit.
18
Repeatsteps8through17foreachadditionalRJ45outputporton
the local transmitter units.
19
TurnonthepowertotheHDMIsource.TheorangeRJ45LEDson
the local units illuminate to indicate a signal is being received from
the source.
201109206-93-3023-EN.indd 26 10/24/2011 10:01:26 AM

Tripp Lite B126-1A1-WP Specifications

General

Brand	Tripp Lite
Model	B126-1A1-WP
Category	Extender
Language	English
