4. Zone Labeling
Each storage shelf is divided into two zones (Red and Blue). The device spaces for each zone are numbered.
Front View
Red Zone
Numbered Device Slots (A)
CSC48AC: 1-8
CSC45AC: 1-7
CSC42AC: 1-7
Numbered Device Slots (B)
CSC48AC: 9-16
CSC45AC: 8-15
CSC42AC: 8-14
Numbered Device Slots (C)
CSC48AC: 17-24
CSC45AC: 16-22
CSC42AC: 15-21
Numbered Device Slots (D)
CSC48AC: 25-32
CSC45AC: 23-30
CSC42AC: 22-28
Numbered Device Slots (E)
CSC48AC: 33-40
CSC45AC: 31-37
CSC42AC: 29-35
Numbered Device Slots (F)
CSC48AC: 41-48
CSC45AC: 38-45
CSC42AC: 36-42
Blue Zone
