Tripp Lite APS2012 - User Manual

Questions and Answers

J
Jeremy BishopAug 7, 2025
What to do if red “LOAD” light is flashing on Tripp Lite Battery Charger?
- M
  melodysmithAug 7, 2025
  If the red “LOAD” operation indicator light is flashing on your Tripp Lite Battery Charger, the inverter is likely overloaded. Reduce the load. To reset the unit, move the Operating Mode Switch to “DC OFF,” wait 1 minute, and then switch to “AUTO/REMOTE” or “CHARGE ONLY.”
K
Krystal NelsonAug 12, 2025
Why is the red “LOW” battery light flashing on my Tripp Lite Battery Charger?
- P
  piercechristyAug 12, 2025
  If the red “LOW” battery indicator light is flashing on your Tripp Lite Battery Charger with the Operating Mode Switch in the “AUTO/REMOTE” position, it could be due to low battery voltage, causing the unit to shut down to protect the battery. If AC power is present, the unit will automatically reset and start recharging. If you're using an external charger, manually reset the unit by moving the Operating Mode Switch to “DC OFF” for two seconds, then back to “AUTO/REMOTE.” Another cause might be a false reading from undersized or poorly connected DC cabling. Ensure you're using DC cable of sufficient size that is sufficiently connected to the Inverter/Charger.
S
Sean GreenAug 22, 2025
Why is my Tripp Lite Battery Charger not recharging?
- T
  Terri ThomasAug 22, 2025
  If your Tripp Lite Battery Charger isn't recharging with AC input present, the connected batteries might be dead, so check and replace them if necessary. Also, the battery fuse might be blown, so inspect and replace it if needed. Lastly, make sure the battery cabling is securely connected; check and tighten or replace the cabling if it's loose.
D
Dillon EdwardsAug 27, 2025
What does it mean when all three “BATT VOLT/ CHRG CURR” LEDs are rapidly flashing on Tripp Lite Battery Charger?
- K
  Kimberly KentAug 27, 2025
  If all three “BATT VOLT/ CHRG CURR” LEDs are rapidly flashing on your Tripp Lite Battery Charger while in “AUTO/ REMOTE” mode, the battery is likely overcharged, causing the unit to shut down to prevent damage. This may be due to connected auxiliary chargers or the unit’s charger. Disconnect any auxiliary chargers. Reset the unit by moving the Operating Mode Switch to “DC OFF,” wait 1 minute, and then switch back to “AUTO/REMOTE.”
J
Jessica NunezSep 1, 2025
What does it mean when all three “BATT VOLT/ CHRG CURR” LEDs are slowly flashing on Tripp Lite Battery Charger?
- C
  Connie JohnsonSep 2, 2025
  If all three “BATT VOLT/ CHRG CURR” LEDs are slowly flashing on your Tripp Lite Battery Charger with the Operating Mode Switch in the “AUTO/ REMOTE” position, the battery is excessively discharged. The unit will shut down to prevent battery damage. Use an auxiliary charger to raise the battery voltage. Check external battery connections and the fuse. The unit will automatically reset when the condition is cleared.
J
John ClarkNov 16, 2025
What to do if Tripp Lite Battery Charger has no AC output?
- Y
  ybarkerNov 16, 2025
  If your Tripp Lite Battery Charger has no AC output and all indicator lights are off, first ensure the unit is properly connected to utility power. If it is, check that the Operating Mode Switch is not set to “OFF” while AC input is present; if it is, switch it to “AUTO/REMOTE” or “CHARGE ONLY.” Also, check the output circuit breaker and reset it if it's tripped. The unit might have shut down due to battery overcharge or excessive battery discharge or overload. In the case of overcharge, disconnect any auxiliary chargers and reset the unit by moving the Operating Mode Switch to “DC OFF,” waiting 1 minute, and then switching to “AUTO/REMOTE” or “CHARGE ONLY.” For excessive battery discharge, use an auxiliary charger to raise the battery voltage and check external battery connections and the...

Summary

Introduction

Important Safety Instructions

Contains critical warnings for safe installation, operation, and storage of the Inverter/Charger, covering location, battery, equipment, and operation.

Operation

Switch Modes

Explains how to select and use the AUTO/REMOTE, CHARGE ONLY, and DC OFF operating modes.

Battery Selection

Selecting Battery Type

Recommends Deep Cycle batteries and matching the type to DIP switch settings for optimal performance.

Matching Amp-Hour Capacity

Mounting

Mounting Instructions

Detailed steps for securely mounting the Inverter/Charger, including clearance and fastener types.

Battery Connection

DC Wiring and Cabling

Guidelines for DC wiring, recommended cable gauge, length, and terminal torque for efficient connection.

Fuse and Polarity

AC Input;Output Connection

Hardwire Connection Procedure

Troubleshooting

Common Problems and Solutions

Lists common symptoms, problems, and their corrections for Inverter/Charger issues.

Tripp Lite APS2012 Specifications

General

Output power	2000 W
Output current	25 A
Output voltage	120 V
Country of origin	China
Product color	Black
Dimensions (WxDxH)	215.9 x 412.8 x 184.2 mm
Package dimensions (W x D x H)	15 x 21.5 x 13.25 \
Package depth	535.9 mm
Package width	365.8 mm
Package height	325.1 mm
Package weight	19500 g
Harmonized System (HS) code	8504.40.9570
Quantity per master (outer) case	1 pc(s)
