Tripp Lite DMCVW4555X2 - Page 5

5
Assembly
2
3
Attach the Columns to the Base
Install the Covers
Attach the left cover (D) and right cover (E) to the base.
Insert the connecting piece (J) into the column to attach the column to the base. Use M8x35 screws (P-C), D8 washers (P-D) and the
6 mm hex key (A-D) to secure the connecting piece and column to the base.
J
P-D
P-C
A-D
D
E
