6. Cable Management
7. Opening and Closing Wall Bracket
Display cables can be routed along top or bottom of wall bracket.
• Use mesh sleeve and cable ties for cable management.
To open wall bracket, push or pull up on locking tabs.
Important: Open position is for service access onl. The bracket must be closed during
normal use.
CABLES
Locking
Tab
Mesh
Sleeve
Cable
Tie
PULL UP
PUSH UP
Locking
Tab
