Browsers must support 128-bit data encryption.
To run the Log Server, you must have the Microsoft Jet OLED8 4.0 (or higher) driver installed.
Supported Web Browsers
Internet Explorer 6 and higher
Firefox 1.5 and higher
Mozilla 1.7 and higher
Safari 4.0 and higher
Opera 9.0 and higher
Netscape 8.1 and higher
Package Includes
B022-U08-IP IP KVM Switch
(x2) 6 ft. USB/PS2 Combo KVM Cable Kits
USB/PS2 Combo Console Cable Kit
RJ11 to DB9 Firmware Upgrade Cable
Rackmount Hardware
External Power Supply (Input: 100-240V, 50/60Hz, 0.5A Output: 5.3V, 2.4A)
Rubber Feet
CD with Owner's Manual and Device Files
Quick Start Guide
Features
1U Rackmount KVM Switch with built-in IP access.
Connect either USB or PS/2 computers using P778-Series USB/PS2 Combo KVM Cable Kits – no need for separate cable kits.
Control up to 8 computers on a single KVM switch.
Daisy-chain multiple KVM switches together to increase the number of connected computers. An additional 15 B022-U16 KVM switches can
be daisy-chained from the B022-U08-IP for a total of 248 connected computers.
Remotely access computers via LAN, WAN or Internet via the Windows™ or Java browser clients.
AP Windows and Java non-browser applications allow the KVM to be remotely accessed via the network without going through a browser.
External USB 1.1 port allows USB peripheral devices to be shared amongst connected computers.
Grayscale feature allows you to view remote sessions in black and white, reducing the amount of data traveling over the network and
improving keyboard/mouse response time over IP.
Web management interface, OSD and toolbars provide convenient, user-friendly operation.
3-level security (Admin, User and Select) – up to 64 accounts can be created.
Panel Array Mode – remotely monitor multiple ports at the same time.
Message board feature allows users who are logged in at the same time to communicate with each other and manage port access.
CD includes a Windows-based log server that records events on the installation and writes them to a searchable database.
Supports RADIUS and LDAP/S authentication.
Flash firmware upgradable via network and included firmware upgrade cable.
Supports both IPv4 and IPv6.
Supports Link Local IPv6 Address and IPv6 Stateless Auto configuration protocol.
Web Management Interface, Remote OSD and Local OSD can be displayed in English, Spanish, French, German and Japanese.
Advanced encryption technologies: 128-bit SSL, 128-bit RC4, 1024-bit RSA, 56-bit DES, 256-bit AES, 168-bit 3DES.
Video resolutions up to 2048 x 1536, DDC2B are supported at the local console. Video resolutions up to 1600 x 1200 @ 60Hz, 24-bit color
depth are supported at the remote console.
Compatible with all major operating systems.
Specifications
OVERVIEW
# Of Users 1
Port Control Push Buttons, Hotkeys, OSD
Max CPU 248
PC/Server PS/2
