6
Multiple Extender Installation
Examples for PoE+ devices (PoE Class 4 that are under 22 watts, or
802.3at compliant):
PoE Source
PoE switch
(802.3af)
15W midspan
(802.3af)
PoE+ switch
(802.3at)
30W midspan
(802.3at)
Maximum Distances
Not applicable Not applicable 200 m / 656 ft. 200 m / 656 ft.
Specifications
IEEE Standards IEEE 802.3af (Power over Ethernet)
IEEE 802.3at (High-Power PoE+ Power over
Ethernet)
IEEE 802.3 (10Base-T Ethernet)
IEEE 802.3ab (Gigabit Ethernet)
IEEE 802.3u (100Base-TX Fast Ethernet)
IEEE 802.3x (Flow control, for full duplex mode)
Media Support 100Base-TX Cat5 UTP/STP RJ45, 8 pin
1000Base-TX Cat5e/6 UTP/STP RJ45, 8 pin
Ports One RJ45 10/100/1000 Mbps Data
+ Power Input port
One RJ45 10/100/1000 Mbps Data
+ Power Output port
Protection Functions Short circuit protection for short GND
Overload protection for currents over 0.6A
18-12-180-9338F9.indb 6 4/17/2019 10:22:31 AM
