Tripp Lite U344-001-VGA User Manual

2
1. Introduction 3
1.1 Features 3
1.2 Package Contents 3
1.3 System Requirements 4
2. Installation 5
3. Using the Adapter 7
3.1 Display Properties 7
3.2 Extending Video to the Add-On Display 9
3.3 Mirroring Video on the Add-On Display 10
3.4 Making the Add-On Display the 11
Primary Display
4. Troubleshooting 12
5. Specifications 14
6. Warranty and Product Registration 15
Table of Contents
15-03-011-933433.indd 2 3/16/2015 3:47:19 PM

Tripp Lite U344-001-VGA Specifications

General

HDCP	Yes
Color depth	64 bit
Connector 1	VGA (D-Sub)
Connector 2	USB Type-A
Power source	USB
Certification	CE, FCC, REACH
Product color	Black
Country of origin	Vietnam
Connector 1 gender	Female
Connector 2 gender	Male
Maximum resolution	2048 x 1152 pixels
Supported video modes	1080p
Connector contacts plating	-
Supported graphics resolutions	2048 x 1152
Sustainability certificates	RoHS
Storage temperature (T-T)	-10 - 80 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	0 - 85 %
Package depth	132.1 mm
Package height	23.1 mm
Package weight	20 g
Quantity per pack	1 pc(s)
Master (outer) case width	245.1 mm
Master (outer) case height	145 mm
Master (outer) case length	150.1 mm
Master (outer) case weight	300 g
Harmonized System (HS) code	84733080
Quantity per master (outer) case	10 pc(s)
Master (outer) case GTIN (EAN/UPC)	10037332186352

Weight and Dimensions

Weight	30 g
