1
11
8
7
6
10
9
4
5
2
3
12
4
PARTS DESCRIPTION
1. Bowl Cover (Plastic)
2. Mixing Bowl
3. Power Unit
4. Slicing Knife
5. Shredding Knife
6. Whisking Blade
7. Chopping Blade
8. Knife Support
9. Juice Drill
10. Filtrating Plate
11. Blade Support
12. Scoop
BEFORE THE FIRST USE
• Remove all packaging of the device.
• Check if the voltage of the appliance corresponds to the main voltage
of your home. Rated voltage : AC220-240V 50Hz.
• Always place the device on a at stable surface and allow at least
10 cm. free space around the unit. This device is not suitable for
integration or outdoor use.
• The device may spread some smell and smoke at rst use, this is normal.
USE
Chopping Function
• Put the plastic bowl on the power unit and turn the handle in clock-
wise direction.
• Put the blade support on the axis in the middle of the bowl, and press
it to the bottom. Then x the chopping blade to the blade support, as
shown in Diagram 2.
Warning: The blade in sharp. Please only hold the plastic part while using.
• Put the food (eg. vegetables) into the bowl, as shown in Diagram 3. Big
piece food needs to be cut into small pieces. (cut 2 CM x 2 CM x 2 CM).
• Put the cover on the bowl, and turn it until hearing the chattering
sound, as shown in Diagram 4.
51 2 43
