Insert 3(three) pieces “AA” batteries at the backside of electronic scoreboard.
Plug the mechanical scoring arm plug into backside of the electronic scoreboard.
Press on/off button at the bottom backside of the electronic scoreboard to play and stop the game.
USE OF YOUR SHOOTOUT
CARE AND USE OF YOUR SHOOTOUT
Congratulations! You have now assembled your Double Shootout.
Please note the Care and Use instructions below.
1. Product can be used OUTDOORS - but must be stored INDOORS.
2. DO NOT sit, climb or lean on the unit.
3.
4. DO NOT place backside of this product against wall as during play, the backside
of product could become damaged or your wall could become damaged.
DO NOT drag the unit when moving it, This will damage the legs.
PRODUCT PARTS LIST 45-6090
KEY PARTS DESCRIPTIONS QTY
H1
H2
H3
H4
H5
H6
H7
H8
T1
P1
P2
P3
P4
P5
P6
P7
P8
P9
P10
P11
P12
P13
P14
P15
P16
C1
A1
A2
K1
M1
45-6090GRH1
45-6090GRH2
45-6090GRH3
45-6090GRH4
45-6090GRH5
45-6090GRH6
45-6090GRH7
45-6090GRH8
45-6090GRT1
45-6090GRP1
45-6090GRP2
45-6090GRP3
45-6090GRP4
45-6090GRP5
45-6090GRP6
45-6090GRP7
45-6090GRP8
45-6090GRP9
45-6090GRP10
45-6090GRP11
45-6090GRP12
45-6090GRP13
45-6090GRP14
45-6090GRP15
45-6090GRP16
45-6090GRC1
45-6090GRA1
45-6090GRA2
45-6090GRK1
45-6090GRM1
M6 x 35 mm Allen Head Bolt
M6 x 60 mm Allen Head Bolt
M6 x 25 mm Allen Head Bolt
M6 Flat Washer
M6 Wing Nut
Plastic Bushing
Wing Bolt
Lock Washer
Allen Wrench
Left Lower Tube Assembly
Right Lower Tube Assembly
Left Middle Tube Assembly
Right Middle Tube Assembly
Front Tube Assembly
Upper Tube
Backboard with Tubes Assembly + Quick Attach Rim Brackets
Ramp Chute
Electronic Scorer
Electronic Scorer Face Plate
Mechanical Scoring Arm
Rim
Rim Net
Control Box
Locking Pin
Scoring Control Box Wire
Rim Bracket (Pre-installed)
Air Pump with Needle
Basketball
Hardware Kit
Owner’s Manual
1
2
8
11
11
2
1
8
1
1
1
1
1
1
2
1
1
1
1
2
2
2
1
2
1
2
1
4
1
1
