Triumph A9758306 - Page 3

3 of 10
Parts supplied: A9758308, A9758309
1. Mounting rack 1 off 8. Screw, M6 x 25 mm 2 off
2. Screw, M8 x 20 mm 2 off 9. Retaining clip 1 off
3. Washer, M8 2 off 10. Square washer 4 off
4. Bolt, M8 x 16 mm 4 off 11. Mounting platform 1 off
5. Bolt, M6 x 20 mm 4 off 12. Cover plate 1 off
6. Lock nut, M6 4 off 13. Screw 2 off
7. S c r e w , M 6 x 2 0 m m 2 o f f
2
1
3
4
5
6
7
8
9
11
10
13
12
