If the engine has recently been running, the exhaust components may be hot to the
touch. Contact with the hot components may cause damage to exposed skin. To avoid
skin damage, always allow the hot parts to cool before working on the exhaust system.
Perform the following operations:
• Seat - Removal
• Battery - Removal
• Catalytic Converter - Removal
• Rear Suspension Unit - Removal
• Rear Suspension Linkage - Removal
Bearings Removal - Drag Link
The drag link bearings cannot be removed undamaged.
1. Secure the drag link in a soft jawed vice.
2. Remove the two seals.
3. Drift out the needle roller bearing.
1. Seals
2. Needle roller bearing
3. Drag link
