Triumph Rocket 3 GT 2021 - Page 1011

973
1. Remove the fir tree clip and detach the rear brake hose from the swinging arm.
1. Fir tree clip
2. P-clip
3. Rear brake hose
2. Remove the bolt and washer securing the right hand outrigger to the upper
crankcase.
3. Engage service tool T3880181 into the slots of the frame adjuster and rotate
anticlockwise to fully loosen the frame adjuster.
1. Frame adjuster
2. Right hand out rigger
