Triumph Rocket 3 GT 2021 - Page 1012

974
4. Remove the bolt and washer securing the left hand outrigger to the upper crankcase.
5. Engage service tool T3880181 into the slots of the frame adjuster and rotate
anticlockwise to fully loosen the frame adjuster.
1. Frame adjuster
2. Left hand out rigger
6. Hold the swinging arm pivot bolt on the left hand side and remove the swinging arm
bolt from the right hand side of the swinging arm.
1. Bolt
