Triumph Rocket 3 GT 2021 - Page 1114

1076
4. Fit the extractor to the mandrel as shown.
1. Mandrel
2. Extractor
5. Position the brake lever assembly with the pivot facing towards the support piece as
shown.
1. Brake lever
2. Pivot assembly
3. Support piece
