1081
8. Support the brake lever, hold the mandrel and turn the installer piece anticlockwise
to release it from the mandrel.
1. Mandrel
2. Installer piece
3. Thread
9. Visually check the pivot sleeve, return spring, brake lever pivot and push rod are
installed as noted during removal.
10. Fit the dust cover to the push rod on the clutch lever.
1. Dust cover
2. Push rod
