11. Apply grease, from the kit, to the push rod that is attached to the master cylinder.
12. Apply grease, from the kit, to the shank of the pivot bolt.
13. Line up the holes of the brake lever and master cylinder, and insert the pivot bolt.
Tighten the pivot bolt to 1 Nm.
14. Fit the pivot bolt lock nut and tighten to 6 Nm.
15. Fit the dust seal into its recess in the master cylinder.
1. Dust cover
2. Master cylinder
16. Check lever operation and make sure the rubber seal is still correctly seated.
