4. Fit the rear wheel spindle bolt.
5. Fit the rear brake caliper and tighten the caliper bolts to 45 Nm.
6. Fit the rear wheel (see Rear Wheel - Installation).
7. Lower the motorcycle to the ground.
8. Tighten the rear wheel spindle bolt to 70 Nm.
Rear Brake Master Cylinder – Removal
Make sure the motorcycle is stabilised and adequately supported.
A correctly supported motorcycle will help prevent it from falling.
An unstable motorcycle may fall, causing injury to the operator or damage to the
motorcycle.
If the engine has recently been running, the exhaust components may be hot to the
touch. Contact with the hot components may cause damage to exposed skin. To avoid
skin damage, always allow the hot parts to cool before working on the exhaust system.
To prevent paint damage, do not spill brake fluid onto any area of the bodywork.
Spilled brake fluid will damage paintwork.
Perform the following operations:
• Rear Wheel - Removal
