Make sure the motorcycle is stabilised and adequately supported.
A correctly supported motorcycle will help prevent it from falling.
An unstable motorcycle may fall, causing injury to the operator or damage to the
motorcycle.
1. If removed, fit the captive nuts to the left and right hand mudguard brackets.
2. Position the right hand mudguard bracket to the right hand fork, fit the fixings but
do not fully tighten at this stage.
3. Position the left hand mudguard bracket to the left hand fork, fit the fixings but do
not fully tighten at this stage.
1. Front fixing (right hand shown)
2. Rear Fixing (right hand shown)
3. Captive nuts
4. Front mudguard bracket (right hand shown)
