Triumph Rocket 3 GT 2021 - Page 1259

1221
NOTICE
Note the routing of the hose connected to the temperature sensor for installation.
2. Remove the fixing and detach the ambient temperature sensor from the subframe.
1. Fixing
2. Electrical connector
3. Hose
4. Temperature sensor
3. Remove the fixings and detach the ABS brake line bracket from the subframe.
