1222
4. Remove the upper fixings and flanged sleeves from the front subframe.
1. Fixings
2. ABS bracket
3. Fixings
4. Flanged sleeves
5. Remove the lower fixings, flanged sleeves and manouevre the front subframe off the
motorcycle.
1. Fixings
2. Flanged sleeves
