1265
4. Route the LF antenna harness as noted for removal and connect to the main harness
(rear mudguard removed for clarity).
1. Connector
2. LF antenna
3. Harness
5. Route the rear light harness as noted for removal and connect to the main harness.
6. Taking care not to damage the USB harness, fit the phone storage box as noted for
removal and tighten the fixings to 3 Nm.
1. Fixings
2. Phone storage box
