2. Release the two fixings to detach the outer battery box from the left hand side of the
rear subframe. Collect the washer and discard the fixing.
1. Fixings
2. Washers
3. Outer battery box
3. Release the fixing to detach the side panel bracket from the right hand side
subframe. Collect the washer and discard the fixing.
1. Fixing (harness removed for clarity)
2. Washer
3. Side panel bracket
