Triumph Rocket 3 GT 2021 - Page 1307

1269
4. Detach the harness clip from the rear subframe rear bridge.
5. Release the fixings to detach the seat lock from the subframe rear bridge. Collect the
washers and discard the fixings.
1. Harness clip
2. Fixings
3. Seat lock
6. Release the fixings and remove the rear bridge.
1. Fixings
2. Rear bridge
