1267
The frame and subframe are painted and can be damaged during removal and
installation of the rear subframe. Use a suitable protective tape such as masking tape
around the area of the frame and rear subframe.
Failure to protect the painted surfaces may cause irreparable damage to both
components.
NOTICE
Before the disconnection of any wiring, note the routing of all wiring and wiring
connectors for installation.
Perform the following operations:
• Seat - Removal
• Battery - Removal
• Fuel Tank - Removal
• Rear Mudguard - Removal
• Side Panels - Removal
• Battery Box - Removal
1. Remove the fixing securing the seat's left hand infill panel to the subframe front
piece. Collect the shouldered washer and discard the fixing.
