1. Noting its orientation for installation, remove the battery strap.
2. Detach the fuse box from the side of the battery box.
3. Disconnect the battery leads, negative (black) lead first.
1. Battery strap
2. Battery strap hook
3. Battery strap support
4. Positive (red) terminal
5. Negative (black) terminal
4. Noting its orientation for installation, remove the battery clamp.
5. Remove the battery from the battery box.
