1350
6. Loosen the two fixings securing the headlight bracket to the front subframe
sufficiently to allow restricted movement of the headlights.
7. To return the headlight alignment to the factory standard position, move the
headlight unit until the front subframe alignment mark and the headlight bracket
mark are aligned.
1. Front subframe alignment mark
2. Headlight bracket mark
8. Tighten the headlight bracket fixings to, front fixing first, 15 Nm.
9. Route the headlamp harnesses into the back of the front subframe as noted for
removal.
