Triumph Rocket 3 GT 2021 - Page 1403

1363
The LED units inside the direction indicators are sealed for life units and must be
replaced in the event of a failure.
Perform the following operations:
• Seat - Removal
• Battery - Removal
• Flyscreen - Removal
NOTICE
Note the routing of the LF antenna harness for installation.
Note the orientation of the LF antenna for installation.
Note the routing of the harnesses under the flyscreen for installation.
1. Remove the fixings and detach the LF antenna from the flyscreen mounting.
2. Disconnect the LF antenna electrical connector from the main harness and remove
the LF antenna.
1. Fixings
2. Electrical connector
3. LF Antenna
