6. Turn the flyscreen mounting over and disconnect the front direction indicator
connectors from the main harness.
1. Right hand direction indicator connectors
2. Left hand direction indicator harnesses
3. Red tape (right hand side only)
7. Loosen the fixing securing the direction indicator to its bracket
8. Remove the direction indicator bracket pinch fixing. Discard the fixing
1. Fixing (direction indicator)
2. Fixing (clamp)
3. Direction indicator clamp
