2. Press in the sides of the left hand plastic grommet to release two of the locating lugs
and remove the grommet.
1. Plastic grommet (harness removed for clarity)
2. Locating lugs (two of three shown)
3. Carefully slide the clutch switch harness out of the handlebar to access the electrical
connector.
4. Disconnect the electrical connector and remove the clutch switch.
Clutch Switch – Installation
Make sure the motorcycle is stabilised and adequately supported.
A correctly supported motorcycle will help prevent it from falling.
An unstable motorcycle may fall, causing injury to the operator or damage to the
motorcycle.
