Perform the following operations:
1. Connect the clutch switch to the switch housing subharness.
2. Carefully slide the clutch switch harness in to the handlebar.
3. Fit the plastic grommet to the left hand side of the handlebar.
1. Plastic grommet (harness removed for clarity)
2. Locating lugs (two of three shown)
4. Attach the clutch switch assembly to the master cylinder as noted for removal.
• Battery - Installation
• Seat - Installation
