1421
2. Release the two fixings securing the left hand heated grip to the handlebar and
collect the two washers.
1. Heated grip
2. Heated grip switch
3. Fixings
3. Carefully slide the heated grip off the handlebar to access the electrical connector.
4. Disconnect the electrical connector and remove the heated grip.
Heated Grip - Installation (if fitted)
Make sure the motorcycle is stabilised and adequately supported.
A correctly supported motorcycle will help prevent it from falling.
An unstable motorcycle may fall, causing injury to the operator or damage to the
motorcycle.
For the installation of the heated twist grip see Heated Grip - Installation (if fitted).
1. Connect the heated grip harness connector to the main harness.
2. Carefully fit the left hand heated grip to the handlebar.
