121
8. Using a suitable Torx T20 screwdriver adjust the throttle adjusters until the words
'THROTTLES BALANCED' appear on the diagnostic tool.
1. Adjusters
9. When balanced, stop the engine and disconnect the diagnostic tool.
10. Refit the Torx T30 blanking screw to the throttle control motor housing and tighten
to 5 Nm.
11. Disconnect the battery, negative (black) lead first.
12. Using proprietary professional automotive workshop equipment approved for fuel
handling, drain any remaining fuel from the fuel tank. Perform the following
operations:
• Plenum - Installation (All Markets Except US) or Plenum - Installation (US
Markets Only)
• Battery – Installation
• Seat - Installation
