175
Incorrect fork oil levels could result in an unsafe riding condition leading to loss of
motorcycle control and an accident.
7. Position the fork assembly as for compression of the fork spring during disassembly.
8. Fit the fork spring in the orientation noted for disassembly.
9. Fit the spring spacer, nylon spacer and the bump rubber.
1. Nylon spacer
2. Spring spacer
3. Bump rubber
If removed, the damping rod lock nut must be fitted with the flat face facing to the top
of the fork. The slightly tapered face must face the fork spring. Incorrect orientation
may lead to a loosening of the lock nut.
