196
7. Hold the assembly together and position the cap and diaphragm seal assembly onto
the reservoir. Make sure the locating lug on the insert fits into its hole in the
reservoir. Tighten the fixings to 1.5 Nm.
1. Reservoir cap
2. Reservoir
3. Locating lug
4. Hole for locating lug
